Spectra Polaris PQ-512/85 AAA Printhead

The printhead is designed for binary jetting using an 80-picoliter native drop size with 8-meters per second nominal drop velocity for jetting fluids in the 8 to 20 centipoise range. Using VersaDrop jetting technology, the printhead is capable of adjustable binary operation at drop sizes up to 150 picoliters with resolutions up to 400 dpi.

•     80 picoliter nominal drop size
•     Resolutions up to 400 dpi
•     512 individual addressable nozzles
•     VersaDrop™ binary jetting capability
•     Supports UV-curable, solvent, and aqueous-based inks
•     Configurable for single- and two-color operation
•     Integral mounting bezel with precision features
•     Optimized for high viscosity jetting fluids
•     Built-in heaters and temperature sensors
•     Operation up to 60°C [140°F]
•     Simplified field repair with no special tools required
